10.5 Åæ¾Ï
Distance platter center to tonearm bearing center 244 mm
Effective length 259.8 mm
Overhang 15.8 mm
Cartridge mount 1/2'' connector, long holes
Minimum distance between mounting surface and platter top 25 mm
Mounting depth 30 mm
Cartridge weight min. 4, max. 16 g
Dynamic mass ca. 12 g
Total weight ca. 300 g
Counterweight 180 g
Scope of delivery tonearm with flying leads (unterminated), tools
Options tonearm with standard 5-pin connector (SME type)
12.1 Åæ¾Ï
Distance platter center to tonearm bearing center 292 mm
Effective length 305.6 mm
Overhang 13.6 mm
Cartridge mount 1/2'' connector, long holes
Minimum distance between mounting surface and platter top 25 mm
Mounting depth 30 mm
Cartridge weight min. 4, max. 16 g
Dynamic mass ca. 14 g
Total weight ca. 350 g
Counterweight 200 g
Scope of delivery tonearm with flying leads (unterminated), tools
Options tonearm with standard 5-pin connector (SME type)
